PWR Universal Water To Oil Engine Oil Cooler 3inX 3inX 6in With 38mm Water Outlets PWO5961

Universal Water To Oil Engine Oil Cooler 3"x 3"x 6" With 38mm Water Outlets

Product Details:

• Universal fitment for easy installation
• High heat transfer
• Low pressure drop
• Dash-10 ORB female ports for male adapters or flanged outlets depending on application
• Start of the art controlled atmosphere brazing process
• Pressure tested and guaranteed
• 1 Year manufactured warranty
• 100% Australian made

The PWR Water to Oil Heat Exchangers are very robust all aluminium construction units featuring complex tube & fin internal cores ideal when there is minimal space for a conventional oil cooler. Plumbed in between the cold side outlet of the radiator and inlet of the water pump, thick-wall extruded tubes carry the coolant flow, whilst the multiple pass baffle configuration within the shell guides the oil flow through a fine, yet robust turbulation fin in-between each tube. This innovative design provides maximum liquid to surface contact on both the coolant and oil passages, yet proves to be a high flowing unit to ensure minimal pressure drops in each of the fluid systems. The result is a very reliable high heat transfer oil cooler in a low pressure drop configuration made 100% in Australia from the finest materials and crafted by our passionate fabricators.

Specifications:

• Natural Aluminium Finish
• Extruded Oil Tube and Water Fin
• Universal Size 3" x 3" x 6"
• 38mm Outlets
• Check Drawing

What's Included:

• x1 Universal Water to Oil Cooler

Compatibility:

• Universal Part
