ACL Balance Shaft Set 1 Set fits Sohc Engine, 2 Sets fits Dohc Engine 3BS8303-SF

Located in Australia, ACL has been providing an extensive replacement product range to a global aftermarket for over 70 years. Their reputation for robust metallurgy, quality, precision, innovation &, of course, performance shows through their products.

SPECIFICATIONS
-High Strength Overlay Plate With Reduced Thickness for Improved Fatigue Properties
-Hardened Steel Backs on All Rod Bearings to Improve Bearing Lining & Retention
-Increased Crush for Improved Bearing Retention
-Elimination of Flash Plating on Back of Bearings & Maximise Grip Between Bearings & Housing
-Increased Eccentricity to Compensate for Bore Distortion at High RPM & Assist in Formation of Hydrodynamic Oil Films
-3/4 Grooved Main Bearings to Optimise Bearing Load Carrying Surface Area & Oil Flow to Conrod Bearings
-Tight Consistent Wall Tolerances to Help Maintain Consistent Clearances
-Enlarged ID Chamfers on Bearing Edges Where Required to Accomodate Large Fillet Radius on Performance Crankshafts
-Material: F810
-Min. Std Shaft Size: 41,945 mm / 1.6514 in
-Max Std Shaft Size: 41,96 mm / 1.6520 in
-Min. Std Tunnel Size: 46 mm / 1.8110 in
-Max Std Tunnel Size: 46,02 mm / 1.8118 in
-Max Overall Length: 23,25 mm / 0.9154 in (8303), 26,25 mm / 1.0335 in (8304), 20,25 mm / 0.7972 in (8305)
